A4988 Stepper Motor Driver- Good Quality

SKU: SB-156

Specifications:
Supply Voltage : 8-35 VDC.
Current : 1.0A (no heatsink ).
Current : 2.0A (with heat-sinking).
logic input : 3 – 5.5V .

Original price was: ₹129.00.Current price is: ₹95.00. (Incl. GST)

Need Help or Support?
Click Here

Free Delivery on all
orders above ₹1999

Unbeatable prices and monthly deals.

  • Didn’t find what you are looking for?
Let Us Know

CONTACT US

Have a question or feedback? Fill out the form below, and we’ll get back to you as soon as possible.

    Payment Methods:

    Description

    The A4988 driver Stepper Motor Driver is a complete micro-stepping motor driver with built-in converter, easy to operate. It operates from 8 V to 35 V and can deliver up to approximately 1 A per phase without a heat sink or forced air flow (it is rated for 2 A per coil with sufficient additional cooling). A4988 driver Stepper Motor Driver includes a fixed off-time current regulator, the regulator can be in slow or mixed decay mode. The converter is the key to the easy implementation of the A4988.

    Provide internal synchronous rectification control circuitry, in order to improve the pulse width modulation (PWM) power consumption during operation
