XL6009 DC-DC Step Up with LED voltmeter display

Description
The XL6009 Step Up Module with Display is a 4A switch current high performance boost ( BOOST ) module. This module uses the second-generation high-frequency switching technology XL6009E1 as the core chip, and its performance far exceeds that of the first-generation technology LM2577 . The XL6009 Step-up module has lower cost and better performance.

Features
XL6009 Step up Module with Display uses XL6009 as main control chip to realize broader scope of application about boosting.
It shows the adjusted results intuitively with the digital tube.
There is no need to use the multimeter, which will be more convenient.
Equipped with the Schottky diode, you need not to be worried about wrong operation.
It adds ventilation hole on PCB to enhance the capacity of heat dissipation.
The booster below 5V works normally, but the display does not work
Built-in 4A high-efficiency MOSFET switch tube, making the efficiency up to 94%( LM2577 current is only 3A ).
Ultra-high switching frequency 400KHz , can achieve very good results with a small-capacity filter capacitor, the ripple is smaller and the volume is smaller. (The frequency of LM2577 is only 50KHz ).
With input display indicator and output display indicator, the IN indicator lights when the Display shows the input voltage, and the OUT indicator lights when the Display shows the output voltage.
With overheat protection and short circuit protection
