Showing 1–12 of 14 results
Shop
0.91 inch IIC 4-Pin OLED Display Module SSD1306 – White
In stock
₹185.00 (Incl. GST)Specifications:
Size: 0.91 inch
Resolution: 128 x 32
Controlling Chip: SSD1306
Display Area: 22.384 x 5.584mm
Driving Voltage: 3-5V
Operating Temperature: -40~70 celsius
Interface Type: IIC
Light Color: White
0.96inch 128×64 OLED 4 Pin Display Module Arduino Compatible (Blue)
In stock
₹169.00 (Incl. GST)Specifications:
Resolution: 128 x 64
Visual Angle: >160°
Input Voltage: 3.3V ~ 6V
Compatible I/O Level: 3.3V, 5V
Mini Size: 2.7 x 2.8cm
Only Need 2 I/O Port Control
Full Compatible with Arduino
Working temperature: -30°C ~ 70°C
Module volume: 32 x 35.5 x 4mm
1.3 Inch IIC 128×64 OLED Display Module 4 Pin – Blue
In stock
₹289.00 (Incl. GST)Specifications:
Display Colour: Blue
Resolution : 128×48 pixels
Driver IC: SH1106
Fully Compatible with Arduino
Working temperature: -30°C ~ 70°C
Factory configured for SPI protocol (can be easily changed to IIC)
Please note: Product Images are shown for illustrative purposes only and may differ from actual product.
1.8 Inch TFT LCD Module 128 x 160 with 4 IO SPI
In stock
₹340.00 (Incl. GST)Specifications:
Display Size: 1.8″
Driver IC: ST7735
Input Voltage (V): 3.3 to 5
Pixel Resolution: 128 x 160
PCB Size (mm): 62×38 (LxW)
Interface Type: SPI
128×64 LCD Green/Yellow
In stock
₹706.00 (Incl. GST)Specifications:
Resolution: 128 x 64
Visual Angle: >160°
Input Voltage: 3.3V ~ 6V
Pixel Color: Yellow/Green
16×2 Character LCD Display With Yellow Backlight
In stock
₹106.00 (Incl. GST)Specifications:
Model: LCD1602
Character Color: Black
Backlight: Yellow
Supply voltage: 5V
Dimensions (L x W x H) mm. : 80 x 36 x 10
16×2 LCD Yellow-Green with I2C Module
In stock
₹169.00 (Incl. GST)Specifications:
Arduino IIC/I2C interface was developed to reduce the IO port usage on Arduino board
I2C adapter allows flexibility in connections
I2C Reduces the overall wirings.
16 characters wide, 2 rows
White text on the Blue background
Single LED backlight included can be dimmed easily with a resistor or PWM.
Interface: I2C
Interface Address: 0x27
Character Color: White
Backlight: Blue
Supply voltage: 5V
2.4 inch SPI Interface 240×320 Touch Screen TFT Colour Display Module
In stock
₹650.00 (Incl. GST)Specifications
Resolution (Pixel) : 240 x 320 RGB
Color Depth : 262K/65K
Backlight : White
Driver IC : ILI9341
Display Size : 2.4″
Operating Voltage : 3.3V to 5V
It is a 2.4″ SPI TFT LCD Screen Module
10pins interface.
The LCD drive ic is ILI9341.
It’s a 240 * 320 (resolution)
2.4 Inch TFT Touch Screen Module for UNO R3 Blue
In stock
₹823.00 (Incl. GST)Specifications:
Input voltage (V) : 3.3
Screen size ( inches) : 2.4
Screen Resolution : 240 x 320
Screen colour : 65 k
Touch Type : Resistive
Length (mm) : 40
Width (mm) : 56
Height (mm) : 12
Weight (gm) : 35
Shipment Weight : 0.037 kg
Shipment Dimensions : 8 × 6 × 2 cm
2.4 inch Touch TFT LCD Arduino Shield With Pen
In stock
₹564.00 (Incl. GST)Specifications:
2.4″ diagonal Touch LCD TFT display
240×320 resolution, 18-bit (262,000) color
8-bit digital interface, plus 4 control lines
Uses digital pins 5-13 and analog 0-3. That means you can use digital pins 2, 3, and analog 4 and 5. Pin 12 is available if not using the microSD
Works with any Arduino UNO
5V compatible! Use with 3.3V or 5V logic
4 white LED backlights. By default but you can connect the transistor to a digital pin for backlight control
Onboard 3.3V 300mA LDO regulator
I2C Module Compatible with 16×2 LCD
In stock
₹55.00 (Incl. GST)Specifications:
IC Chip: PCF8574
Power Supply: 5V
Serial I2C control of LCD display using PCF8574
Backlight can be enabled or disabled via a jumper on the board.
Contrast control via a potentiometer.
Can have 8 modules on a single I2C bus (change address via solder jumpers) address, allowing
Size: 41.6 x 19.2 mm
Compatible with Arduino Boards, Raspberry pi
JHD 20×4 character LCD Display with Green/Yellow Backlight
In stock
₹411.00 (Incl. GST)Specifications:
20 Characters x 4 Lines
Works directly with ATMEGA, ARDUINO, PIC, and many other microcontrollers/kits.
4 or 8 bit data I/O interface
Low power consumption
Color: Yellow/Green
